ARM Cortex-A76 Core User Manual

B2.64 ID_DFR0_EL1, AArch32 Debug Feature Register 0, EL1
The ID_DFR0_EL1 provides top-level information about the debug system in AArch32.
Bit field descriptions
ID_DFR0_EL1 is a 32-bit register, and is part of the Identification registers functional group.
This register is Read Only.
31 12 11 8 7 04 324 23 20 19 16 1528 27
PerfMon MProfDbg MMapTrc CopTrc CopSDbg CopDbg
RES0
Figure B2-48 ID_DFR0_EL1 bit assignments
RES0, [31:28]
RES0 Reserved.
PerfMon, [27:24]
Indicates support for performance monitor model:
4 Support for Performance Monitor Unit version 3 (PMUv3) system registers, with a
16-bit evtCount field.
MProfDbg, [23:20]
Indicates support for memory-mapped debug model for M profile cores:
0 This product does not support M profile Debug architecture.
MMapTrc, [19:16]
Indicates support for memory-mapped trace model:
1 Support for Arm trace architecture, with memory-mapped access.
In the Trace registers, the ETMIDR gives more information about the implementation.
CopTrc, [15:12]
Indicates support for coprocessor-based trace model:
0 This product does not support Arm trace architecture.
RES0, [11:8]
RES0 Reserved.
CopSDbg, [7:4]
Indicates support for coprocessor-based Secure debug model:
8 This product supports the Armv8.2 Debug architecture.
CopDbg, [3:0]
Indicates support for coprocessor-based debug model:
8 This product supports the Armv8.2 Debug architecture.
