ARM Cortex-A76 Core User Manual

D9.72 TRCVICTLR, ViewInst Main Control Register
The TRCVICTLR controls instruction trace filtering.
Bit field descriptions
The TRCVICTLR is a 32-bit register.
31 0789101115 121619202324
SSSTATUS
TRCRESET
TRCERR
EXLEVEL_S
EXLEVEL_NS
6 34
SEL
TYPE
RES0
Figure D9-69 TRCVICTLR bit assignments
RES0, [31:24]
RES0 Reserved.
EXLEVEL_NS, [23:20]
In Non-secure state, each bit controls whether instruction tracing is enabled for the
corresponding exception level:
0 Trace unit generates instruction trace, in Non-secure state, for exception level n.
1 Trace unit does not generate instruction trace, in Non-secure state, for exception level
n.
The exception levels are:
Bit[20] Exception level 0.
Bit[21] Exception level 1.
Bit[22] Exception level 2.
Bit[23] RAZ/WI. Instruction tracing is not implemented for exception level 3.
EXLEVEL_S, [19:16]
In Secure state, each bit controls whether instruction tracing is enabled for the corresponding
exception level:
0 Trace unit generates instruction trace, in Secure state, for exception level n.
1 Trace unit does not generate instruction trace, in Secure state, for exception level n.
The exception levels are:
Bit[16] Exception level 0.
Bit[17] Exception level 1.
Bit[18] RAZ/WI. Instruction tracing is not implemented for exception level 2.
Bit[19] Exception level 3.
RES0, [15:12]
RES0 Reserved.
