ARM Cortex-A76 Core User Manual

D9.73 TRCVIIECTLR, ViewInst Include-Exclude Control Register
The TRCVIIECTLR defines the address range comparators that control the ViewInst Include/Exclude
control.
Bit field descriptions
The TRCVIIECTLR is a 32-bit register.
31 0
EXCLUDE
16 15
INCLUDE
1920 34
RES0
Figure D9-70 TRCVIIECTLR bit assignments
RES0, [31:20]
RES0 Reserved.
EXCLUDE, [19:16]
Defines the address range comparators for ViewInst exclude control. One bit is provided for
each implemented Address Range Comparator.
RES0, [15:4]
RES0 Reserved.
INCLUDE, [3:0]
Defines the address range comparators for ViewInst include control.
Selecting no include comparators indicates that all instructions must be included. The exclude
control indicates which ranges must be excluded.
One bit is provided for each implemented Address Range Comparator.
Bit fields and details not provided in this description are architecturally defined. See the Arm
®
Architecture Reference Manual Armv8, for Armv8-A architecture profile.
The TRCVIIECTLR can be accessed through the external debug interface, offset 0x084.
D9 ETM registers
D9.73 TRCVIIECTLR, ViewInst Include-Exclude Control Register
100798_0300_00_en Copyright © 2016–2018 Arm Limited or its affiliates. All rights
reserved.
D9-585
Non-Confidential
