A8.7 Error injection

To support testing of error handling software, the Cortex-A76 core can inject errors in the error detection

logic.

The following table describes all the possible types of error that the core can encounter and therefore

inject.

Table A8-3 Errors injected in the Cortex-A76 core

Error type Description

Corrected errors A CE is generated for a single-bit ECC error on L1 data caches and L2 caches, both on data and tag RAMs.

Deferred errors A DE is generated for a double-bit ECC error on L1 data caches and L2 caches, but only on data RAM.

Uncorrected errors A UE is generated for a double-bit ECC error on L1 data caches and L2 caches, but only on tag RAM.

The following table describes the registers that handle error injection in the Cortex-A76 core.

Table A8-4 Error injection registers

ERR0PFGFR_EL1 The ERR Pseudo Fault Generation Feature register defines which errors can be injected.

ERR0PFGCTLR_EL1 The ERR Pseudo Fault Generation Control register controls the errors that are injected.

ERR0PFGCDNR_EL1 The ERR Pseudo Fault Generation Count Down register controls the fault injection timing.

Note

This mechanism simulates the corruption of any RAM but the data is not actually corrupted.
