B2.84 MIDR_EL1, Main ID Register, EL1

The MIDR_EL1 provides identification information for the core, including an implementer code for the

device and a device ID number.

Bit field descriptions

MIDR_EL1 is a 32-bit register, and is part of the Identification registers functional group.

This register is Read Only.

VariantImplementer

31 23 20 19 16 15 4 3 0

Architecture PartNum Revision

Figure B2-68 MIDR_EL1 bit assignments

Implementer, [31:24]

Indicates the implementer code. This value is:

0x41 ASCII character 'A' - implementer is Arm Limited.

Variant, [23:20]

Indicates the variant number of the core. This is the major revision number x in the rx part of the

rxpy description of the product revision status. This value is:

0x3 r3p0.

Architecture, [19:16]

Indicates the architecture code. This value is:

0xF Defined by CPUID scheme.

PartNum, [15:4]

Indicates the primary part number. This value is:

0xD0B Cortex-A76 core.

Revision, [3:0]

Indicates the minor revision number of the core. This is the minor revision number y in the py

part of the rxpy description of the product revision status. This value is:

0x0 r3p0.

Configurations

The MIDR_EL1 is architecturally mapped to external MIDR_EL1 register.

Bit fields and details that are not provided in this description are architecturally defined. See the

Arm

Architecture Reference Manual Armv8, for Armv8-A architecture profile.

B2 AArch64 system registers

B2.84 MIDR_EL1, Main ID Register, EL1

reserved.

B2-266

Non-Confidential
