B4.2 AArch64 physical GIC CPU interface system register summary
The following table lists the AArch64 physical GIC CPU interface system registers that have
IMPLEMENTATION DEFINED bits.
See the Arm
®
Generic Interrupt Controller Architecture Specification for more information and a
complete list of AArch64 physical GIC CPU interface system registers.
Table B4-2 AArch64 physical GIC CPU interface system register summary
Name Op0 Op1 CRn CRm Op2 Type Description
ICC_AP0R0_EL1 3 0 12 8 4 RW B4.3 ICC_AP0R0_EL1, Interrupt Controller Active Priorities Group 0
Register 0, EL1 on page B4-315
ICC_AP1R0_EL1 3 0 12 9 0 RW B4.4 ICC_AP1R0_EL1, Interrupt Controller Active Priorities Group 1
Register 0 EL1 on page B4-316
ICC_BPR0_EL1 3 0 12 8 3 RW B4.5 ICC_BPR0_EL1, Interrupt Controller Binary Point Register 0,
EL1 on page B4-317
ICC_BPR1_EL1 3 0 12 12 3 RW B4.6 ICC_BPR1_EL1, Interrupt Controller Binary Point Register 1,
EL1 on page B4-318
ICC_CTLR_EL1 3 0 12 12 4 RW B4.7 ICC_CTLR_EL1, Interrupt Controller Control Register, EL1
on page B4-319
ICC_CTLR_EL3 3 6 12 12 4 RW B4.8 ICC_CTLR_EL3, Interrupt Controller Control Register, EL3
on page B4-321
ICC_SRE_EL1 3 0 12 12 5 RW B4.9 ICC_SRE_EL1, Interrupt Controller System Register Enable
Register, EL1 on page B4-323
ICC_SRE_EL2 3 4 12 9 5 RW B4.10 ICC_SRE_EL2, Interrupt Controller System Register Enable
register, EL2 on page B4-324
ICC_SRE_EL3 3 6 12 12 5 RW B4.11 ICC_SRE_EL3, Interrupt Controller System Register Enable
register, EL3 on page B4-326
