C3.4 AMU events
The following table describes the counters that are implemented in the Cortex-A76 core and the mapping
to fixed and programmable events.
Table C3-1 Mapping of counters to fixed events
Activity
monitor
counter <n>
Event
type
Event Event
number
Description
0 Fixed Cycles at core
frequency
0x11
Cycles count.
1 Fixed Cycles at constant
frequency
0xEF
This counter is used to replicate the generic system counter that is
incremented on a constant basis, and not incremented depending on
the PE frequency core.
2 Fixed Instructions retired
0x08
Instruction architecturally executed. This counter increments for
every instruction that is executed architecturally, including
instructions that fail their condition code check.
3 Fixed First miss
0xF0
The first miss event tracks whether any external load miss is
outstanding and starts counting only from a first-miss until data
returns for that miss. The counter does not count for any remaining
part of overlapping accesses, only counting again when the first-
miss condition is re-detected.
4 Fixed High activity
0xF1
Instructions executing through the design which act as a hint for
potential high power activity.
