A4.8 Power domain states for power modes

The power domains can be controlled independently to give different combinations when powered-up

and powered-down.

However, only some powered-up and powered-down domain combinations are valid and supported. The

following information shows the supported power domain states for the Cortex-A76 core.

The PDCPU power domain supports the power states described in the following table.

Table A4-3 Power state description

Power state Description

Off Core off. Power to the block is gated.

Ret Core retention. Logic and RAM retention power only.

On Core on. Block is active.

Caution

States that are not shown in the following tables are unsupported and must not occur.

The following table describes the power modes, and the corresponding power domain states for

individual cores. The power mode of each core is independent of all other cores in the cluster.

Table A4-4 Supported core power domain states

Power mode Power domain state Description

Debug recovery On Core on.

On On Core on.

Core dynamic retention Ret Core in retention.

Off (emulated) On Core on.

Off Off Core off.

Deviating from the legal power modes can lead to UNPREDICTABLE results. You must comply with the

dynamic power management and powerup and powerdown sequences described in the following

sections.

A4 Power management

A4.8 Power domain states for power modes

reserved.

A4-57
