ARM Cortex-A76 Core User Manual

A8.1 Cache ECC and parity
The Cortex-A76 core implements the RAS extension to the Armv8-A architecture which provides
mechanisms for standardized reporting of the errors generated by cache protection mechanisms.
When configured with core cache protection, the Cortex-A76 core can detect and correct a 1-bit error in
any RAM and detect 2-bit errors in some RAMs.
Note
For information about SCU-L3 cache protection, see the Arm
®
DynamIQ
™
Shared Unit Technical
Reference Manual.
The RAS extension improves the system by reducing unplanned outages:
• Transient errors can be detected and corrected before they cause application or system failure.
• Failing components can be identified and replaced.
• Failure can be predicted ahead of time to allow replacement during planned maintenance.
Errors that are present but not detected are known as latent or undetected errors. A transaction carrying a
latent error is corrupted. In a system with no error detection, all errors are latent errors and are silently
propagated by components until either:
• They are masked and do not affect the outcome of the system. These are benign or false errors.
• They affect the service interface of the system and cause failure. These are silent data corruptions.
The severity of a failure can range from minor to catastrophic. In many systems, data or service loss is
regarded as more of a minor failure than data corruption, as long as backup data is available.
The RAS extension focuses on errors that are produced from hardware faults, which fall into two main
categories:
• Transient faults.
• Persistent faults.
The RAS extension describes data corruption faults, which mostly occur in memories and on data links.
RAS concepts can also be used for the management of other types of physical faults found in systems,
such as lock-step errors, thermal trip, and mechanical failure. The RAS extension provides a common
programmers model and mechanisms for fault handling and error recovery.
A8 Reliability, Availability, and Serviceability (RAS)
A8.1 Cache ECC and parity
100798_0300_00_en Copyright © 2016–2018 Arm Limited or its affiliates. All rights
reserved.
A8-102
Non-Confidential

ARM Cortex-A76 Core Specifications

General

Architecture	ARMv8.2-A
Microarchitecture	Cortex-A76
Pipeline Depth	13 stages
Frequency	Up to 3.0 GHz
Process Technology	7nm
Core Type	Out-of-order
NEON	Yes
Power Efficiency	Improved over Cortex-A75
Performance Improvement	35% over Cortex-A75
Core Count	1-4 cores per cluster
ISA Support	AArch64 and AArch32
Branch Prediction	Yes
L1 Data Cache	32KB, per core
L2 Cache	256KB or 512KB, per core
L3 Cache	Up to 4MB
Memory Support	LPDDR4, LPDDR4X, DDR4
DynamIQ Shared Unit (DSU)	DynamIQ Shared Unit (DSU)
Cryptography Extensions	Yes
Virtualization Support	Yes
L1 Cache	64 KB per core
