ARM Cortex-A76 Core User Manual

A8.2 Cache protection behavior
The configuration of the RAS extension that is implemented in the Cortex-A76 core includes cache
protection.
In this case, the Cortex-A76 core protects against errors that result in a RAM bitcell holding the incorrect
value.
The RAMs in the Cortex-A76 core have the following capability:
SED
Single Error Detect. One bit of parity is applicable to the entire word. The word size is specific
for each RAM and depends on the protection granule.
Interleaved parity
One bit of parity is applicable to the even bits of the word, and one bit of parity is applicable to
the odd bits of the word.
SECDED
Single Error Correct, Double Error Detect.
Table A8-1 Cache protection behavior on page A8-103 indicates which protection type is applied to
each RAM.
The core can progress and remain functionally correct when there is a single bit error in any RAM.
If there are multiple single bit errors in different RAMs, or within different protection granules within the
same RAM, then the core also remains functionally correct.
If there is a double bit error in a single RAM within the same protection granule, then the behavior
depends on the RAM:
• For RAMs with SECDED capability, the core detects and either reports or defers the error. If the error
is in a cache line containing dirty data, then that data might be lost.
• For RAMs with only SED, the core does not detect a double bit error. This might cause data
corruption.
If there are three or more bit errors within the same protection granule, then depending on the RAM and
the position of the errors within the RAM, the core might or might not detect the errors.
The cache protection feature of the core has a minimal performance impact when no errors are present.
Table A8-1 Cache protection behavior
RAM Protection type Protection granule Correction behavior
L1 instruction cache tag 1 parity bit 31 bits The line that contains the error is invalidated
from the L1 instruction cache and fetched
again from the subsequent memory system.
L1 instruction cache data SED 72 bits The line that contains the error is invalidated
from the L1 instruction cache and fetched
again from the subsequent memory system.
L1 BTB None - -
L1 GHB None - -
L1 BPIQ None - -
L1 data cache tag SECDED 34 bits + 7 bits for ECC attached to
the word.
The cache line that contains the error gets
evicted, corrected in line, and refilled to the
core.
A8 Reliability, Availability, and Serviceability (RAS)
A8.2 Cache protection behavior
100798_0300_00_en Copyright © 2016–2018 Arm Limited or its affiliates. All rights
reserved.
A8-103
Non-Confidential

ARM Cortex-A76 Core Specifications

General

Architecture	ARMv8.2-A
Microarchitecture	Cortex-A76
Pipeline Depth	13 stages
Frequency	Up to 3.0 GHz
Process Technology	7nm
Core Type	Out-of-order
NEON	Yes
Power Efficiency	Improved over Cortex-A75
Performance Improvement	35% over Cortex-A75
Core Count	1-4 cores per cluster
ISA Support	AArch64 and AArch32
Branch Prediction	Yes
L1 Data Cache	32KB, per core
L2 Cache	256KB or 512KB, per core
L3 Cache	Up to 4MB
Memory Support	LPDDR4, LPDDR4X, DDR4
DynamIQ Shared Unit (DSU)	DynamIQ Shared Unit (DSU)
Cryptography Extensions	Yes
Virtualization Support	Yes
L1 Cache	64 KB per core
