ARM Cortex-A76 Core User Manual

D9.28 TRCEXTINSELR, External Input Select Register
The TRCEXTINSELR controls the selectors that choose an external input as a resource in the ETM trace
unit. You can use the Resource Selectors to access these external input resources.
Bit field descriptions
31 08 716 1524 23
SEL2 SEL1 SEL0SEL3
2829 2021 1213 45
RES0
Figure D9-26 TRCEXTINSELR bit assignments
RES0, [31:29]
RES0 Reserved.
SEL3, [28:24]
Selects an event from the external input bus for External Input Resource 3.
RES0, [23:21]
RES0 Reserved.
SEL2, [20:16]
Selects an event from the external input bus for External Input Resource 2.
RES0, [15:13]
RES0 Reserved.
SEL1, [12:8]
Selects an event from the external input bus for External Input Resource 1.
RES0, [7:5]
RES0 Reserved.
SEL0, [4:0]
Selects an event from the external input bus for External Input Resource 0.
Bit fields and details not provided in this description are architecturally defined. See the Arm
®
Architecture Reference Manual Armv8, for Armv8-A architecture profile.
The TRCEXTINSELR can be accessed through the external debug interface, offset 0x120.
D9 ETM registers
D9.28 TRCEXTINSELR, External Input Select Register
100798_0300_00_en Copyright © 2016–2018 Arm Limited or its affiliates. All rights
reserved.
D9-533
Non-Confidential
