ARM Cortex-A76 Core User Manual

B2.85 MPIDR_EL1, Multiprocessor Affinity Register, EL1
The MPIDR_EL1 provides an additional core identification mechanism for scheduling purposes in a
cluster.
Bit field descriptions
MPIDR_EL1 is a 64-bit register, and is part of the Other system control registers functional group.
This register is Read Only.
Aff1 Aff0
063 16 15
8 7
Aff2
2324
MT
2930
U
32 31
Aff3
40 39 25
Aff1
11 10
RES0
RES1
Figure B2-69 MPIDR_EL1 bit assignments
RES0, [63:40]
RES0 Reserved.
Aff3, [39:32]
Affinity level 3. Highest level affinity field.
CLUSTERID
Indicates the value read in the CLUSTERIDAFF3 configuration signal.
RES1, [31]
RES1 Reserved.
U, [30]
Indicates a single core system, as distinct from core 0 in a cluster. This value is:
0 Core is part of a multiprocessor system. This is the value for implementations with
more than one core, and for implementations with an ACE or CHI master interface.
RES0, [29:25]
RES0 Reserved.
MT, [24]
Indicates whether the lowest level of affinity consists of logical cores that are implemented
using a multithreading type approach. This value is:
1 Performance of PEs at the lowest affinity level is very interdependent.
Affinity0 represents threads. Cortex-A76 is not multithreaded, but may be in a system
with other cores that are multithreaded.
Aff2, [23:16]
Affinity level 2. Second highest level affinity field.
B2 AArch64 system registers
B2.85 MPIDR_EL1, Multiprocessor Affinity Register, EL1
100798_0300_00_en Copyright © 2016–2018 Arm Limited or its affiliates. All rights
reserved.
B2-267
Non-Confidential

ARM Cortex-A76 Core Specifications

General

Architecture	ARMv8.2-A
Microarchitecture	Cortex-A76
Pipeline Depth	13 stages
Frequency	Up to 3.0 GHz
Process Technology	7nm
Core Type	Out-of-order
NEON	Yes
Power Efficiency	Improved over Cortex-A75
Performance Improvement	35% over Cortex-A75
Core Count	1-4 cores per cluster
ISA Support	AArch64 and AArch32
Branch Prediction	Yes
L1 Data Cache	32KB, per core
L2 Cache	256KB or 512KB, per core
L3 Cache	Up to 4MB
Memory Support	LPDDR4, LPDDR4X, DDR4
DynamIQ Shared Unit (DSU)	DynamIQ Shared Unit (DSU)
Cryptography Extensions	Yes
Virtualization Support	Yes
L1 Cache	64 KB per core
