ARM Cortex-A76 Core

D9.39 TRCIDR12, ID Register 12
The TRCIDR12 returns the number of conditional instruction right-hand keys that the trace unit can use.
Bit field descriptions
The TRCIDR10 is a 32-bit register.
31 0
NUMCONDKEY
Figure D9-37 TRCIDR12 bit assignments
NUMCONDKEY, [31:0]
The number of conditional instruction right-hand keys that the trace unit can use, including
normal and special keys.
0 Number of conditional instruction right-hand keys.
Bit fields and details not provided in this description are architecturally defined. See the Arm
®
Architecture Reference Manual Armv8, for Armv8-A architecture profile.
The TRCIDR12 can be accessed through the external debug interface, offset 0x190.
D9 ETM registers
D9.39 TRCIDR12, ID Register 12
