ARM Cortex-A76 Core User Manual

D9.23 TRCDEVARCH, Device Architecture Register
The TRCDEVARCH identifies the ETM trace unit as an ETMv4 component.
Bit field descriptions
The TRCDEVARCH is a 32-bit register.
ARCHITECT
31 21 20 19 16 15 0
REVISION ARCHID
PRESENT
Figure D9-21 TRCDEVARCH bit assignments
ARCHITECT, [31:21]
Defines the architect of the component:
0x4 Arm JEP continuation.
0x3B Arm JEP 106 code.
PRESENT, [20]
Indicates the presence of this register:
0b1 Register is present.
REVISION, [19:16]
Architecture revision:
0x02 Architecture revision 2.
ARCHID, [15:0]
Architecture ID:
0x4A13 ETMv4 component.
Bit fields and details not provided in this description are architecturally defined. See the Arm
®
Architecture Reference Manual Armv8, for Armv8-A architecture profile.
The TRCDEVARCH can be accessed through the external debug interface, offset 0xFBC.
D9 ETM registers
D9.23 TRCDEVARCH, Device Architecture Register
100798_0300_00_en Copyright © 2016–2018 Arm Limited or its affiliates. All rights
reserved.
D9-527
Non-Confidential
