A6.6 Direct access to internal memory
The Cortex-A76 core provides a mechanism to read the internal memory that is used by the L1 caches,
L2 cache, and TLB structures through implementation defined system registers. This functionality can be
useful when debugging software or hardware issues.
When the core executes in AArch64 state, there are six read-only registers that are used to access the
contents of the internal memory. The internal memory is selected by programming the implementation-
defined RAMINDEX register (using SYS #6, c15, c0, #0 instruction). These operations are available
only in EL3. In all other modes, executing these instructions results in an Undefined Instruction
exception. The data is read from read-only registers as shown in the following table.
Table A6-1 AArch64 registers used to access internal memory
Register name Function Access Operation Rd Data
IDATA0_EL3 Instruction Register 0 Read-only
S3_6_c15_c0_0
Data
IDATA1_EL3 Instruction Register 1 Read-only
S3_6_c15_c0_1
Data
IDATA2_EL3 Instruction Register 2 Read-only
S3_6_c15_c0_2
Data
DDATA0_EL3 Data Register 0 Read-only
S3_6_c15_c1_0
Data
DDATA1_EL3 Data Register 1 Read-only
S3_6_c15_c1_1
Data
DDATA2_EL3 Data Register 2 Read-only
S3_6_c15_c1_2
Data
A6.6.1 Encoding for L1 instruction cache tag, L1 instruction cache data, L1 BTB, L1 GHB, L1 TLB
instruction, and BPIQ
The following tables show the encoding required to select a given cache line.
Table A6-2 L1 instruction cache tag location encoding
Bit fields of Rd Description
[31:24] RAMID = 0x00
[23:20] Reserved
[19:18] Way
[17:14] Reserved
[13:6] Index [13:6]
[5:0] Reserved
Table A6-3 L1 instruction cache data location encoding
Bit fields of Rd Description
[31:24] RAMID = 0x01
[23:20] Reserved
[19:18] Way
[17:14] Reserved
[13:3] Index [13:3]
[2:0] Reserved
A6 Level 1 memory system
A6.6 Direct access to internal memory
100798_0300_00_en Copyright © 2016–2018 Arm Limited or its affiliates. All rights
reserved.
A6-80
Non-Confidential
