ARM Cortex-A76 Core User Manual

B2.78 ID_PFR1_EL1, AArch32 Processor Feature Register 1, EL1
The ID_PFR1_EL1 provides information about the programmers model and architecture extensions
supported by the core.
Bit field descriptions
ID_PFR1_EL1 is a 32-bit register, and is part of the Identification registers functional group.
This register is Read Only.
31 12 11 8 7 0
GIC CPU
4 316 15
Virtualization
20 192728
GenTimer MProgMod Security ProgMod
24 23
Virt_frac Sec_frac
Figure B2-62 ID_PFR1_EL1 bit assignments
GIC CPU, [31:28]
GIC CPU support:
0 GIC CPU interface is disabled, GICCDISABLE is HIGH, or not implemented.
1 GIC CPU interface is implemented and enabled, GICCDISABLE is LOW.
Virt_frac, [27:24]
0 No features from the Armv7 Virtualization Extensions are implemented.
Sec_frac, [23:20]
0 No features from the Armv7 Virtualization Extensions are implemented.
GenTimer, [19:16]
Generic Timer support:
1 Generic Timer supported.
Virtualization, [15:12]
Virtualization support:
0 Virtualization not implemented.
MProgMod, [11:8]
M profile programmers model support:
0 Not supported.
Security, [7:4]
Security support:
0 Security not implemented.
ProgMod, [3:0]
Indicates support for the standard programmers model for Armv4 and later.
Model must support User, FIQ, IRQ, Supervisor, Abort, Undefined, and System modes:
0 Not supported.
