D9.56 TRCPIDR2, ETM Peripheral Identification Register 2

The TRCPIDR2 provides information to identify a trace component.

Bit field descriptions

The TRCPIDR2 is a 32-bit register.

31 0

DES_1

Revision

JEDEC

RES0

Figure D9-54 TRCPIDR2 bit assignments

RES0, [31:8]

RES0 Reserved.

Revision, [7:4]

0x0 ETM revision.

JEDEC, [3]

0b1 RES1. Indicates a JEP106 identity code is used.

DES_1, [2:0]

0b011 Arm Limited. This is bits[6:4] of JEP106 ID code.

Bit fields and details not provided in this description are architecturally defined. See the Arm

Architecture Reference Manual Armv8, for Armv8-A architecture profile.

The TRCPIDR2 can be accessed through the external debug interface, offset 0xFE8.

D9 ETM registers

D9.56 TRCPIDR2, ETM Peripheral Identification Register 2

reserved.

D9-566
