B2.65 ID_ISAR0_EL1, AArch32 Instruction Set Attribute Register 0, EL1
The ID_ISAR0_EL1 provides information about the instruction sets implemented by the core in
AArch32.
Bit field descriptions
ID_ISAR0_EL1 is a 32-bit register, and is part of the Identification registers functional group.
This register is Read Only.
31 28 27 24 23 20 19 16 15 12 11 8 7 4 3 0
Divide Debug Coproc CmpBranch Bitfield BitCount Swap
RES0
Figure B2-49 ID_ISAR0_EL1 bit assignments
RES0, [31:28]
RES0 Reserved.
Divide, [27:24]
Indicates the implemented Divide instructions:
0x2 • SDIV and UDIV in the T32 instruction set.
• SDIV and UDIV in the A32 instruction set.
Debug, [23:20]
Indicates the implemented Debug instructions:
0x1 BKPT.
Coproc, [19:16]
Indicates the implemented Coprocessor instructions:
0x0 None implemented, except for instructions separately attributed by the architecture to
provide access to AArch32 System registers and System instructions.
CmpBranch, [15:12]
Indicates the implemented combined Compare and Branch instructions in the T32 instruction
set:
0x1 CBNZ and CBZ.
Bitfield, [11:8]
Indicates the implemented bit field instructions:
0x1 BFC, BFI, SBFX, and UBFX.
BitCount, [7:4]
Indicates the implemented Bit Counting instructions:
0x1 CLZ.
