B4.1 CPU interface registers
Each CPU interface block provides the interface for the Cortex-A76 core that interfaces with a GIC
distributor within the system.
The Cortex-A76 core only supports system register access to the GIC CPU interface registers. The
following table lists the three types of GIC CPU interface system registers supported in the Cortex-A76
core.
Table B4-1 GIC CPU interface system register types supported in the Cortex-A76 core.
Register prefix Register type
ICC Physical GIC CPU interface system registers.
ICV Virtual GIC CPU interface system registers.
ICH Virtual interface control system registers.
Access to virtual GIC CPU interface system registers is only possible at Non-secure EL1.
Access to ICC registers or the equivalent ICV registers is determined by HCR_EL2. See
B2.51 HCR_EL2, Hypervisor Configuration Register, EL2 on page B2-212.
For more information on the CPU interface, see the Arm
®
Generic Interrupt Controller Architecture
Specification.
B4 GIC registers
B4.1 CPU interface registers
