ARM Cortex-A76 Core User Manual

A5.2 TLB organization
The TLB is a cache of recently executed page translations within the MMU. The Cortex-A76 core
implements a two-level TLB structure. The TLB stores all page sizes and is responsible for breaking
these down in to smaller pages when required for the data or instruction L1 TLB.
A5.2.1 Instruction L1 TLB
The instruction L1 TLB is implemented as a 48-entry fully associative structure. This TLB caches entries
at the 4KB, 16KB, 64KB, 2MB, and 32MB granularity of VA to PA mapping only.
A hit in the instruction L1 TLB provides a single CLK cycle access to the translation, and returns the PA
to the instruction cache for comparison. It also checks the access permissions to signal an Instruction
Abort.
A5.2.2 Data L1 TLB
The data L1 TLB is a 48-entry fully associative TLB that is used by load and store operations. The cache
entries have 4KB, 16KB, 64KB, 2MB, and 512MB granularity of VA to PA mappings only.
A hit in the data L1 TLB provides a single CLK cycle access to the translation, and returns the PA to the
data cache for comparison. It also checks the access permissions to signal a Data Abort.
A5.2.3 L2 TLB
The L2 TLB structure is shared by instruction and data. It handles misses from the instruction and data
L1 TLBs.
The following table describes the characteristic that applies to the L2 TLB.
Table A5-3 Characteristic of the L2 TLB
Characteristic Note
5-way, set associative,
1280-entry cache
Stores:
• VA to PA mappings for 4KB, 16KB, 64KB, 2MB, 32MB, 512MB, and 1GB block sizes.
• Intermediate physical address (IPA) to PA mappings for 2MB and 1GB (in a 4KB translation
granule), 32MB (in a 16K translation granule), and 512MB (in a 64K granule) block sizes. Only
Non-secure EL1 and EL0 stage 2 translations are cached.
• Intermediate PAs obtained during a translation table walk.
Access to the L2 TLB usually takes three cycles. If a different page or block size mapping is used, then
access to the L2 TLB can take longer.
The L2 TLB supports four translation table walks in parallel (four TLB misses), and can service two
TLB lookups while the translation table walks are in progress. If there are six successive misses, the L2
TLB will stall.
Note
The main TLB is invalidated automatically at reset unless the DISCACHEINVLD signal is set HIGH
when the Cortex-A76 core is reset. This signal must only be used in diagnostic mode. If caches are not
invalidated on reset, their functionality cannot be guaranteed. See the Arm
®
DynamIQ
™
Shared Unit
Technical Reference Manual for more information on DISCACHEINVLD.
A5 Memory Management Unit
A5.2 TLB organization
100798_0300_00_en Copyright © 2016–2018 Arm Limited or its affiliates. All rights
reserved.
A5-64
Non-Confidential

ARM Cortex-A76 Core Specifications

General

Architecture	ARMv8.2-A
Microarchitecture	Cortex-A76
Pipeline Depth	13 stages
Frequency	Up to 3.0 GHz
Process Technology	7nm
Core Type	Out-of-order
NEON	Yes
Power Efficiency	Improved over Cortex-A75
Performance Improvement	35% over Cortex-A75
Core Count	1-4 cores per cluster
ISA Support	AArch64 and AArch32
Branch Prediction	Yes
L1 Data Cache	32KB, per core
L2 Cache	256KB or 512KB, per core
L3 Cache	Up to 4MB
Memory Support	LPDDR4, LPDDR4X, DDR4
DynamIQ Shared Unit (DSU)	DynamIQ Shared Unit (DSU)
Cryptography Extensions	Yes
Virtualization Support	Yes
L1 Cache	64 KB per core
