ARM Cortex-A76 Core

To Next Page

To Previous Page

D3.6 EDDEVID, External Debug Device ID Register 0

The EDDEVID provides extra information for external debuggers about features of the debug

implementation.

Bit field descriptions

The EDDEVID is a 32-bit register.

31 028 27 24 23

AuxRegs

RES0

Figure D3-5 EDDEVID bit assignments

RES0, [31:28]

RES0 Reserved.

AuxRegs, [27:24]

Indicates support for Auxiliary registers:

0x0 None supported.

RES0, [23:0]

RES0 Reserved.

Bit fields and details not provided in this description are architecturally defined. See the Arm

Architecture Reference Manual Armv8, for Armv8-A architecture profile.

The EDDEVID can be accessed through the external debug interface, offset 0xFC8.

D3 Memory-mapped debug registers

D3.6 EDDEVID, External Debug Device ID Register 0

reserved.

D3-424

Non-Confidential
