ARM Cortex-A76 Core User Manual

D9.1 ETM register summary
This section summarizes the ETM trace unit registers.
All ETM trace unit registers are 32-bit wide. The description of each register includes its offset from a
base address. The base address is defined by the system integrator when placing the ETM trace unit in
the Debug-APB memory map.
The following table lists all of the ETM trace unit registers.
Table D9-1 ETM trace unit register summary
Offset Name Type Reset Description
0x004
TRCPRGCTLR RW
0x00000000
D9.60 TRCPRGCTLR, Programming Control Register on page D9-570
0x00C
TRCSTATR RO
0x00000003
D9.68 TRCSTATR, Status Register on page D9-579
0x010
TRCCONFIGR RW UNK D9.20 TRCCONFIGR, Trace Configuration Register on page D9-521
0x018
TRCAUXCTLR RW
0x00000000
D9.5 TRCAUXCTLR, Auxiliary Control Register on page D9-503
0x020
TRCEVENTCTL0R RW UNK D9.26 TRCEVENTCTL0R, Event Control 0 Register on page D9-530
0x024
TRCEVENTCTL1R RW UNK D9.27 TRCEVENTCTL1R, Event Control 1 Register on page D9-532
0x02C
TRCSTALLCTLR RW UNK D9.67 TRCSTALLCTLR, Stall Control Register on page D9-578
0x030
TRCTSCTLR RW UNK D9.71 TRCTSCTLR, Global Timestamp Control Register
on page D9-582
0x034
TRCSYNCPR RW UNK D9.69 TRCSYNCPR, Synchronization Period Register on page D9-580
0x038
TRCCCCTLR RW UNK D9.7 TRCCCCTLR, Cycle Count Control Register on page D9-506
0x03C
TRCBBCTLR RW UNK D9.6 TRCBBCTLR, Branch Broadcast Control Register on page D9-505
0x040
TRCTRACEIDR RW UNK D9.70 TRCTRACEIDR, Trace ID Register on page D9-581
0x080
TRCVICTLR RW UNK D9.72 TRCVICTLR, ViewInst Main Control Register on page D9-583
0x084
TRCVIIECTLR RW UNK D9.73 TRCVIIECTLR, ViewInst Include-Exclude Control Register
on page D9-585
0x088
TRCVISSCTLR RW UNK D9.74 TRCVISSCTLR, ViewInst Start-Stop Control Register
on page D9-586
0x100
TRCSEQEVR0 RW UNK D9.62 TRCSEQEVRn, Sequencer State Transition Control Registers 0-2
on page D9-572
0x104
TRCSEQEVR1 RW UNK D9.62 TRCSEQEVRn, Sequencer State Transition Control Registers 0-2
on page D9-572
0x108
TRCSEQEVR2 RW UNK D9.62 TRCSEQEVRn, Sequencer State Transition Control Registers 0-2
on page D9-572
0x118
TRCSEQRSTEVR RW UNK D9.63 TRCSEQRSTEVR, Sequencer Reset Control Register
on page D9-574
0x11C
TRCSEQSTR RW UNK D9.64 TRCSEQSTR, Sequencer State Register on page D9-575
0x120
TRCEXTINSELR RW UNK D9.28 TRCEXTINSELR, External Input Select Register on page D9-533
0x140
TRCCNTRLDVR0 RW UNK D9.18 TRCCNTRLDVRn, Counter Reload Value Registers 0-1
on page D9-519
D9 ETM registers
D9.1 ETM register summary
