ARM Cortex-A76 Core User Manual

D9.33 TRCIDR4, ID Register 4
The TRCIDR4 indicates the resources available in the ETM trace unit.
Bit field descriptions
The TRCIDR4 is a 32-bit register.
31 02324 16 15 8 7 342728 20 19
NUMDVCNUMPCNUMSSCCNUMCIDC
NUMACPAIRS
91112
NUMRSPAIRS
NUMVMIDC
SUPPDAC
RES0
Figure D9-31 TRCIDR4 bit assignments
NUMVMIDC, [31:28]
Indicates the number of VMID comparators available for tracing:
0x1 One VMID comparator is available.
NUMCIDC, [27:24]
Indicates the number of CID comparators available for tracing:
0x1 One Context ID comparator is available.
NUMSSCC, [23:20]
Indicates the number of single-shot comparator controls available for tracing:
0x1 One single-shot comparator control is available.
NUMRSPAIRS, [19:16]
Indicates the number of resource selection pairs available for tracing:
0x7 Eight resource selection pairs are available.
NUMPC, [15:12]
Indicates the number of core comparator inputs available for tracing:
0x0 Core comparator inputs are not implemented.
RES0, [11:9]
RES0 Reserved.
SUPPDAC, [8]
Indicates whether the implementation supports data address comparisons: This value is:
0 Data address comparisons are not implemented.
NUMDVC, [7:4]
Indicates the number of data value comparators available for tracing:
0x0 Data value comparators not implemented.
NUMACPAIRS, [3:0]
Indicates the number of address comparator pairs available for tracing:
