ARM Cortex-A76 Core User Manual

A1.4 Supported standards and specifications
The Cortex-A76 core implements the Armv8-A architecture and some architecture extensions. It also
supports interconnect, interrupt, timer, debug, and trace architectures.
Table A1-2 Compliance with standards and specifications
Architecture
specification or
standard
Version Notes
Arm architecture
Armv8-A
• AArch32 execution state at Exception level EL0 only. AArch64
execution state at all Exception levels (EL0-EL3).
• A64, A32, and T32 instruction sets.
Arm architecture
extensions
• Armv8.1-A extensions
• Armv8.2-A extensions
• Cryptographic extension
• RAS extension
• Armv8.3-A extensions
• Armv8.4-A dot product
instructions
• Armv8.5-A extensions
• The Cortex-A76 core implements the LDAPR instructions
introduced in the Armv8.3-A extensions.
• The Cortex-A76 core optionally implements the SDOT and UDOT
instructions introduced in the Armv8.4-A extensions.
• The Cortex-A76 core implements the PSTATE Speculative Store
Bypass Safe (SSBS) bit introduced in the Armv8.5-A extension.
Generic Interrupt
Controller
GICv4 -
Generic Timer Armv8-A 64-bit external system counter with timers within each core.
PMU PMUv3 -
Debug Armv8-A With support for the debug features added by the Armv8.2-A
extensions.
CoreSight CoreSightv3 -
Embedded Trace
Macrocell
ETMv4.2 Instruction trace only.
See Additional reading on page 19 for a list of architectural references.
A1 Introduction
A1.4 Supported standards and specifications
100798_0300_00_en Copyright © 2016–2018 Arm Limited or its affiliates. All rights
reserved.
A1-29
Non-Confidential

ARM Cortex-A76 Core Specifications

General

Architecture	ARMv8.2-A
Microarchitecture	Cortex-A76
Pipeline Depth	13 stages
Frequency	Up to 3.0 GHz
Process Technology	7nm
Core Type	Out-of-order
NEON	Yes
Power Efficiency	Improved over Cortex-A75
Performance Improvement	35% over Cortex-A75
Core Count	1-4 cores per cluster
ISA Support	AArch64 and AArch32
Branch Prediction	Yes
L1 Data Cache	32KB, per core
L2 Cache	256KB or 512KB, per core
L3 Cache	Up to 4MB
Memory Support	LPDDR4, LPDDR4X, DDR4
DynamIQ Shared Unit (DSU)	DynamIQ Shared Unit (DSU)
Cryptography Extensions	Yes
Virtualization Support	Yes
L1 Cache	64 KB per core
