Dell MXL 10GbE - 39 PIM-Sparse Mode (PIM-SM)

39
PIM-Sparse Mode (PIM-SM)
The protocol-independent multicast (PIM) commands are supported by the Dell Networking Operating
System (OS).
This chapter contains the following sections:
• IPv4 PIM-Sparse Mode Commands
• IPv6 PIM-Sparse Mode Commands
IPv4 PIM-Sparse Mode Commands
The following describes the IPv4 PIM-sparse mode (PIM-SM) commands.
clear ip pim rp-mapping
The bootstrap router (BSR) feature uses this command to remove all or particular rendezvous point (RP)
advertisement.
Syntax
clear ip pim rp-mapping rp-address
Parameters
rp-address (OPTIONAL) Enter the RP address in dotted decimal format
(A.B.C.D).
Command
Modes
EXEC Privilege
Command
History
Version 9.2(0.0) Introduced on the MXL 10/40GbE Switch IO Module.
clear ip pim tib
Clear PIM tree information from the PIM database.
Syntax
clear ip pim tib [group]
Parameters
group (OPTIONAL) Enter the multicast group address in dotted
decimal format (A.B.C.D).
PIM-Sparse Mode (PIM-SM)
1013
