hello-time — changes the time interval between BPDUs.
max-hops
Configure the maximum hop count.
Syntax
max-hops number
To return to the default values, use the no max-hops command.
Parameters
range Enter a number for the maximum hop count. The range is
from 1 to 40. The default is 20.
Defaults 20 hops
Command
Modes
MULTIPLE SPANNING TREE
Command
History
Version 8.3.16.1 Introduced on the MXL 10/40GbE Switch IO Module.
Usage
Information
The max-hops command is a configuration command that applies to both the IST
and all MST instances in the MSTP region. The BPDUs sent out by the root switch
set the remaining-hops parameter to the configured value of max-hops. When a
switch receives the BPDU, it decrements the received value of the remaining hops
and uses the resulting value as remaining-hops in the BPDUs. If the remaining-
hops reach zero, the switch discards the BPDU and ages out any information that it
holds for the port.
msti
Configure multiple spanning tree instance, bridge priority, and one or multiple VLANs mapped to the MST
instance.
Syntax
msti instance {vlan range | bridge-priority priority}
To disable mapping or bridge priority, use the no msti instance {vlan range
| bridge-priority priority} command.
Parameters
msti instance Enter the MSTP iInstance. The range is from zero (0) to 63.
vlan range Enter the keyword vlan then the identifier range value. The
range is from 1 to 4094.
bridge-priority
priority
Enter the keywords bridge-priority then a value in
increments of 4096 as the bridge priority. The range is from
zero (0) to 61440.
902
Multiple Spanning Tree Protocol (MSTP)
