Dell MXL 10GbE - Clear Gvrp Statistics

Example
R3#show gvrp brief
GVRP Feature is currently enabled.
Port GVRP Status Edge-Port
----------------------------------------------
Gi 3/0 Disabled No
Gi 3/1 Disabled No
Gi 3/2 Enabled No
Gi 3/3 Disabled No
Gi 3/4 Disabled No
Gi 3/5 Disabled No
Gi 3/6 Disabled No
Gi 3/7 Disabled No
Gi 3/8 Disabled No
R3#show gvrp brief
Related
Commands
show gvrp statistics — displays the GVRP statistics.
clear gvrp statistics
Clear GVRP statistics on an interface.
Syntax
clear gvrp statistics {interface interface | summary}
Parameters
interface
interface
Enter the following keywords and slot/port or number
information:
• For a Port Channel interface, enter the keywords port-
channel then a number. The range is from 1 to 128.
• For a 10-Gigabit Ethernet interface, enter the keyword
TenGigabitEthernet then the slot/port information.
• For a 40-Gigabit Ethernet interface, enter the keyword
fortyGigE then the slot/port information.
summary Enter the keyword summary to display just a summary of the
GVRP statistics.
Defaults none
Command
Modes
• EXEC
• EXEC Privilege
Command
History
Version 8.3.16.1 Introduced on the MXL 10/40GbE Switch IO Module.
Usage
Information
Invalid messages/attributes skipped can occur in the following cases:
• The incoming GVRP PDU has an incorrect length.
• “End of PDU” was reached before the complete attribute could be parsed.
• The Attribute Type of the attribute that was being parsed was not the GVRP VID
Attribute Type (0x01).
542
GARP VLAN Registration (GVRP)
