Command
Modes
CONFIGURATION
Command
History
Version 9.2(0.0) Introduced on the M I/O Aggregator. This command is
supported in Programmable-Mux (PMUX) mode only.
Version 8.3.16.1 Introduced on the MXL 10/40GbE Switch IO Module.
Usage
Information
If an error occurs in an ETS output-policy configuration, the configuration is
ignored and the scheduler and bandwidth allocation settings are reset to the ETS
default values (all priorities are in the same ETS priority group and bandwidth is
allocated equally to each priority).
If an error occurs when a port receives a peer’s ETS configuration, the port’s
configuration is reset to the previously configured ETS output policy. If no ETS
output policy was previously applied, the port is reset to the default ETS
parameters.
Related
Commands
• scheduler — schedules the priority traffic in port queues.
• bandwidth-percentage — bandwidth percentage allocated to the priority traffic
in port queues.
scheduler
Configure the method used to schedule priority traffic in port queues.
Syntax
scheduler value
To remove the configured priority schedule, use the no scheduler command.
Parameters
value Enter schedule priority value. The valid values are:
• strict: strict-priority traffic is serviced before any other
queued traffic.
• werr: weighted elastic round robin (werr) provides low-
latency scheduling for priority traffic on port queues.
Defaults Weighted elastic round robin (WERR) scheduling is used to queue priority traffic.
Command
Modes
POLICY-MAP-OUT-ETS
Command
History
Version 9.2(0.0) Introduced on the M I/O Aggregator. This command is
supported in Programmable-Mux (PMUX) mode only.
Version 8.3.16.1 Introduced on the MXL 10/40GbE Switch IO Module.
PMUX Mode of the MXL 10/40GbE Switch I/O Module
1441
