ip-any Enter the keyword ip-any to support IPv4 and IPv6 traffic.
ip-
precedence-list
Enter the IP precedence value(s) as the match criteria.
Separate values by commas — no spaces ( 1,2,3 ) or indicate
a list of values separated by a hyphen (1-3). The range is from
0 to 7.
set-ip-dscp
value
(OPTIONAL) Enter the keywords set-ip-dscp then the IP
DSCP value. The matched traffic is marked with the DSCP
value. The range is from 0 to 63.
Defaults none
Command
Modes
CLASS-MAP CONFIGURATION (config-class-map)
Command
History
Version 9.5(0.0) Introduced the support for ipv6 and ip-any options on the
MXL 10/40GbE Switch.
Version 8.3.16.1 Introduced on the MXL 10/40GbE Switch IO Module.
Usage
Information
To access this command, enter the class-map command. After the class map is
identified, you can configure the match criteria.
The match ip precedence command and the match ip dscp command are
mutually exclusive.
Up to eight precedence values can be matched in one match statement. For
example, to indicate the IP precedence values 0 1 2 3, enter either the match ip
precedence 0-3 or match ip precedence 0,1,2,3 command.
NOTE: Only one of the IP precedence values must be a successful match
criterion, not all of the specified IP precedence values must match.
Related
Commands
class-map — identifies the class map.
match mac access-group
Configure a match criterion for a class map, based on the contents of the designated MAC ACL.
Syntax
match mac access-group {mac-acl-name}
Parameters
mac-acl-name Enter a MAC ACL name. Its contents is used as the match
criteria in the class map.
Defaults none
1086
Quality of Service (QoS)
