• 1 is the least secure version.
• 3 is the most secure of the security modes.
• 2c allows transmission of informs and counter 64, which
allows for integers twice the width of what is normally
allowed.
The default is 1.
auth (OPTIONAL) Enter the keyword auth to specify
authentication of a packet without encryption.
noauth (OPTIONAL) Enter the keyword noauth to specify no
authentication of a packet.
priv (OPTIONAL) Enter the keyword priv to specify both
authentication and then scrambling of the packet.
read name (OPTIONAL) Enter the keyword read then a name (a string
of up to 20 characters long) as the read view name. The
default is
GlobalView and is assumed to be every object
belonging to the internet (1.3.6.1) OID space.
write name (OPTIONAL) Enter the keyword write then a name (a string
of up to 20 characters long) as the write view name.
notify name (OPTIONAL) Enter the keyword notify then a name (a
string of up to 20 characters long) as the notify view name.
access-list-
name
(Optional) Enter the standard IPv4 access list name (a string
up to 16 characters long).
Defaults As above.
Command
Modes
CONFIGURATION
Command
History
Version 8.3.16.1 Introduced on the MXL 10/40GbE Switch IO Module.
Usage
Information
The following Example specifies the group named harig as a version 3 user
requiring both authentication and encryption and read access limited to the read
named rview.
NOTE: The number of configurable groups is limited to 16 groups.
Example
Dell#conf
Dell(conf)# snmp-server group harig 3 priv read rview
Dell#
Related
Commands
show snmp group — displays the group name, security model, view status, and
storage type of each group.
show running-config — displays the SNMP running configuration.
1230
Simple Network Management Protocol (SNMP) and Syslog
