Field Description
FC-MAP FCoE MAC address-prefix value - The unique 24-bit MAC
address prefix that identifies a fabric.
FKA-ADV-period Time interval (in seconds) used to transmit FIP keepalive
advertisements.
FCF Priority The priority used by a server to select an upstream FCoE
forwarder.
Config-State Indicates whether the configured FCoE and FC parameters
in the FCoE map are valid: Active (all mandatory FCoE and
FC parameters are correctly configured) or Incomplete
(either the FC-MAP value, fabric ID, or VLAN ID are not
correctly configured).
Oper-State Operational status of link to the fabric: Up (link is up and
transmitting FC traffic), Down (link is down and not
transmitting FC traffic), Link-wait (link is up and waiting for
FLOGI to complete on peer FC port), or Removed (port has
been shut down).
Members M I/O Aggregator and MXL 10/40GbE Switch with the FC
Flex IO module Ethernet and FC ports that are members of
the dedicated FCoE VLAN that carries storage traffic to the
specified fabric.
Example
FTOS#show fcoe-map brief
Fabric-Name Fabric-Id Vlan-Id FC-MAP FCF-Priority Config-
State Oper-State
test 16 16 0efc02 128
ACTIVE UP
cnatest 1003 1003 0efc03 128
ACTIVE UP
sitest 1004 1004 0efc04 128
ACTIVE DOWN
FTOS#show fcoe-map si
Fabric Name si
Fabric Id 1004
Vlan Id 1004
Vlan priority 3
FC-MAP 0efc04
FKA-ADV-Period 8
Fcf Priority 128
Config-State ACTIVE
Oper-State DOWN
Members
Related
Commands
fcoe-map — creates an FCoE map which contains the parameters used in the
communication between servers and a SAN fabric.
