Row Heading Description
Address Displays the IP address of the ARP entry.
Age(min) Displays the age (in minutes) of the ARP entry.
Hardware Address Displays the MAC address associated with the ARP entry.
Interface Displays the first two letters of the interfaces type and the
slot/port associated with the ARP entry.
VLAN Displays the VLAN ID, if any, associated with the ARP entry.
CPU Lists which CPU the entries are stored on.
Example
Dell>show arp
Protocol Address Age(min) Hardware Address Interface VLAN
CPU
-----------------------------------------------------
Internet 10.11.8.6 167 00:01:e9:45:00:03 Ma 0/0 -
CP
Internet 10.11.68.14 124 00:01:e9:45:00:03 Ma 0/0 -
CP
Internet 10.11.209.254 0 00:01:e9:45:00:03 Ma 0/0 -
CP
Example
(Private VLAN)
NOTE: In this example, Line 1 shows community VLAN 200 (in primary VLAN
10) in a PVLAN. Line 2 shows primary VLAN 10.
Dell#show arp
Protocol Address Age(min) Hardware Address Interface VLAN
CPU
---------------------------------------------------------------
Internet 5.5.5.1 - 00:01:e8:43:96:5e - Vl 10 pv
200 CP
Internet 5.5.5.10 - 00:01:e8:44:99:55 - Vl
10 CP
Internet 10.1.2.4 1 00:01:e8:d5:9e:e2 Ma 0/0
- CP
Internet 10.10.10.4 1 00:01:e8:d5:9e:e2 Ma 0/0
- CP
Internet 10.16.127.53 1 00:01:e8:d5:9e:e2 Ma 0/0
- CP
Internet 10.16.134.254 20 00:01:e8:d5:9e:e2 Ma 0/0
- CP
Internet 133.33.33.4 1 00:01:e8:d5:9e:e2 Ma 0/0
- CP
Usage
Information
The following describes the show arp summary command shown in the
following example.
Row Heading Description
Total Entries Lists the total number of ARP entries in the ARP table.
Static Entries Lists the total number of configured or static ARP entries.
Dynamic Entries Lists the total number of learned or dynamic ARP entries.
IPv4 Routing
