6. BASIC OPERATION
100
6. Place the DATE item in the area where the TIME item was displayed.
To move an item, drag it.
To resize an item, drag the green handles at the four corners of the item.
The position and size of an item snap to the grid selected by Grid Size in the layout
window.
You can also use the Area tab to move and resize an item.
The coordinates at the upper left corner of the screen are (0, 0). Those at the lower
right corner are (1920, 1080). Using these references, set the coordinates of the upper
left corner of the item (x0, y0) and the lower right corner (x1, y1).
The minimum size is 90×60.
If the layout window gets in the way, move it or close it. When using a mouse, to
display a window that you closed, double-click in the layout screen.
If multiple items are on top of each other, items in the back may not be selectable. If
you need to select such item, click or tap the item on the Main or Sub tab. The selected
item will move to the front.
c) Superimpose the vector on the picture
7. Select the VECTOR item, and click Background Transparent on the Option tab.
Background Transparent is for making the background transparent when an item is
superimposed on a picture.
8. Place the VECTOR item on top of the picture.
Resize as necessary.
d) Add audio
9. On the Main tab, click or tap AUDIO.
The AUDIO item appears.
10. Place the AUDIO item in the area where the VECTOR item was originally displayed.
e) Add TIME to the status
11. Click or tap the STATUS item.
12. On the Option tab, click or tap Time.
The TIME item on the Sub tab can be placed anywhere. Time on the Option tab is
displayed at the top of the selected item. You cannot change the display position or size.
f) Apply the changes
13. Right-click or tap in the layout screen, and click or tap SAVE.
The measurement screen returns.
If you click or tap EXIT, all the changes that you made up to that point will be canceled.
