6 DELETE
Deletes the selected item.
7 DEFAULT LAYOUT
Resets the layout to the initial settings defined for each measurement mode. Grid Size is
not reset.
8 Grid Size: 10x10 / 30x30
Select the grid size.
The position and size of items snap to the grid specified here.
9 Main
Measurement items.
• WFM
Shows the video signal waveform display.
• PIC
Shows the picture display.
• VECTOR
Click or tap this after selecting the display mode on the VECTOR tab to show the vector
waveform. A CIE chromaticity diagram will not be displayed properly if the VECT item is
overlapping other items.
• AUDIO
Click or tap this after selecting the display mode on the AUDIO tab to show audio.
• STATUS
Click or tap this after selecting the display mode on the STATUS tab to show the status.
• EYE
Click or tap this after selecting the display mode on the EYE tab to show the eye pattern
or jitter.
If LV5350 or LV7300-SER02 is not installed, the message “Not installed” is displayed.
