7. SYSTEM SETTINGS
139
• HDR Mode
Turn of the HDR measurement, or select the HDR signal standard. If you select an HDR
signal standard, HDR signals can be measured on the video-signal-waveform, vector, and
picture displays.
HLG and PQ refer to ITU-R BT.2100, and S-Log3, C-Log and Log-C refer to the log curve
output from cameras of other manufacturers.
OFF: An HDR scale is not displayed.
HLG: When HLG Scale is 1200% (default value), 0 to 100% is displayed as 0
to 1200%.
When HLG Scale is 100% (default value), 0 to 100% is displayed as 0 to
100%.
PQ: 0 to 100 % is displayed as 0 to 10000 Nits.
S-Log3: If 0 to 100% is set to 64 to 940, 95 to 940 is displayed as 0 to 2055%.
C-Log: Displays the percentage with the SDI code value 128 assumed to 0%
and 614 assumed to be 100%
Log-C: EI = 200
Displays the percentage with the SDI code value 95 assumed to 0.39%
and 853 assumed to be 83%
EI = 400
Displays the percentage with the SDI code value 95 assumed to 0.39%
and 917 assumed to be 90%
EI = 800
Displays the percentage with the SDI code value 95 assumed to 0.39%
and 976 assumed to be 95%
EI = 1600
Displays the percentage with the SDI code value 95 assumed to 0.39%
and 1022 assumed to be 94%
PayloadID UnSpec:S-Log3:
Operates in OFF (SDR-TV), HLG, or PQ mode according to the payload
ID information. When the payload ID information is Unspecified, the
instrument operates in S-Log3 mode.
PayloadID UnSpec:C-Log:
Operates in OFF (SDR-TV), HLG, or PQ mode according to the payload
ID information. When the payload ID information is Unspecified, the
instrument operates in C-Log mode.
PayloadID UnSpec:Log-C:
Operates in OFF (SDR-TV), HLG, or PQ mode according to the payload
ID information. When the payload ID information is Unspecified, the
instrument operates in Log-C mode.
