7. SYSTEM SETTINGS
140
• Ref. Level
When HDR Mode is set to HLG or PQ, select the reference level for the program
production. When HDR Mode is set to S-Log3, C-Log, or Log-C, it is set to default value
and cannot be selected.
When the HDR mode is set to PayloadID UnSpec:S-Log3, PayloadID UnSpec:C-Log, or
PayloadID UnSpec:Log-C, select the level by combining the HLG and PQ levels. The HLG
or PQ reference level selected with Ref. Level is applied according to the payload ID
information. When the payload ID information is Unspecified, the S-Log3, C-Log, or Log-C
reference level is applied. When the payload ID information is OFF (SDR-TV), the
reference level is not applied.
On the video signal waveform display, the selected reference level is shown using broken
lines on the scale.
On the picture display, the selected reference level is set to the REF default value on the
HDR signal CINEZONE display. The REF default value is applied when you press the
function dial (F•D).
HDR Mode = HLG
50% / 75%
HDR Mode = PQ
51% / 58%
HDR Mode = S-Log3
61%
HDR Mode = C-Log
63%
HDR Mode = Log-C
58%
HDR Mode = PayloadID UnSpec:S-Log3
HLG:50%,PQ:51% / HLG:50%,PQ:58% / HLG:75%,PQ:51% / HLG:75%,PQ:58%
HDR Mode = PayloadID UnSpec:C-Log
HLG:50%,PQ:51% / HLG:50%,PQ:58% / HLG:75%,PQ:51% / HLG:75%,PQ:58%
HDR Mode = PayloadID UnSpec:Log-C
HLG:50%,PQ:51% / HLG:50%,PQ:58% / HLG:75%,PQ:51% / HLG:75%,PQ:58%
• Variable
Select whether to enable the reference level setting.
The default reference level is set to the Ref.Level value.
OFF / ON
