7. SYSTEM SETTINGS
141
• EI
When HDR mode is set to Log-C, select the EI value.
200 / 400 / 800 / 1600
• System Gamma
When HDR Mode is set to HLG or S-Log3, turn system gamma on or off.
If system gamma is set to on, the scale corresponding to the HDR signal of the video
signal waveform display and picture display is shown in Nits, which is a unit of display
intensity for HLG displays.
When HDR Mode is set to HLG, gamma 1.2 is used to calculate the intensity with the full
scale ranging up to 1000Nits.
When HDR Mode is set to S-Log3, the intensity is displayed with the full scale ranging up
to 3000Nits.
OFF / ON
• Range
When HDR Mode is set to HLG or PQ, select the range.
Narrow / Full
• HLG Scale
When HDR Mode is set to HLG, select the HDR scale display.
1200%: 0 to 100 % is displayed as 0 to 1200%.
100% 0 to 100 % is displayed as 0 to 100%.
