13. Picture Screen
266
• General Display Description
• Generation Number
The clear screen log entries are listed in order with the most recent events listed first.
By turning the function dial (F•D) to the right, you can scroll the screen to view older
entries in the log. Press the function dial (F•D) to display the latest entries in the log.
• Time Code
In the clear screen log, entries are recorded using the time code specified on the
CAPTURE & DISPLAY tab of the SYS menu. Set the time code to LTC or VITC. D-VITC is
not supported.
[See also] 7.2.5, “Configuring the Information Display”
• Log Entry Contents
The meanings of the displayed log contents are shown below.
CS: Detection of a clear screen command
T_DSP: Detection of closed caption display
• Starting or Stopping the Log
To start or stop the clear screen log, follow the procedure below.
Procedure
PIC → F•1 PIC CONFIG → F•5 SUPER IMPOSE → F•5 CS LOG → F•2 LOG: START / STOP
• Clearing the Log
To clear the clear screen log, follow the procedure below.
Procedure
PIC → F•1 PIC CONFIG → F•5 SUPER IMPOSE → F•5 CS LOG → F•3 CLEAR
• Log Operation Mode
The clear screen log can record up to 5,000 entries.
To select the action to perform when more than 5,000 events occur, follow the procedure
below.
Procedure
PIC → F•1 PIC CONFIG → F•5 SUPER IMPOSE → F•5 CS LOG → F•4 LOG MODE: OVER
WT / STOP
Settings
OVER WT: Old logs are discarded and overwritten.
STOP: Logs after the 5,000 events are not recorded.
