16. Status Display
345
• Level Error
Select whether to detect level errors. If you set this to OFF, you cannot configure the
following settings.
ON / OFF
• Luminance Upper
Set the luminance level error upper limit. An error occurs when the input signal level
exceeds the specified value.
In the 5-bar Y display, levels that are greater than or equal to the specified value are
displayed in red.
-51 - 766mV
• Luminance Lower
Set the luminance level error lower limit. An error occurs when the input signal level goes
below the specified value.
In the 5-bar Y display, levels that are less than or equal to the specified value are
displayed in red.
-51 - 766mV
• Chroma Upper
Set the chroma level error upper limit. An error occurs when the input signal level exceeds
the specified value.
-400 - 399mV
• Chroma Lower
Set the chroma level error lower limit. An error occurs when the input signal level goes
below the specified value.
-400 - 399mV
• Area
Specify the percentage of the active picture area over which errors must occur to be
recognized as an error.
0.0 - 1.0 - 5.0％
• Duration
Set the number of consecutive video frames over which errors must occur to be
recognized as an error.
1 - 60 Frames
