Leader LV5300A - Page 494

19. Network Control
477
MIB
OID
SYNTAX
ACCESS
VALUE/RANGE
2 = ei-400
3 = ei-800
4 = ei-1600
l40sysHdrInputDEi
l40sysHdrTBL.20
INTEGER
R/W
1 = ei-200
2 = ei-400
3 = ei-800
4 = ei-1600
l40sysHdrInputADetectPayload
Id
l40sysHdrTBL.21
INTEGER
R/W
1 = off
2 = on
l40sysHdrInputBDetectPayload
Id
l40sysHdrTBL.22
INTEGER
R/W
1 = off
2 = on
l40sysHdrInputARefLvHlg
l40sysHdrTBL.25
INTEGER
R/W
1 = reflv-50-per
2 = reflv-75-per
l40sysHdrInputBRefLvHlg
l40sysHdrTBL.26
INTEGER
R/W
1 = reflv-50-per
2 = reflv-75-per
l40sysHdrInputARefLvPq
l40sysHdrTBL.29
INTEGER
R/W
1 = reflv-51-per
2 = reflv-58-per
l40sysHdrInputBRefLvPq
l40sysHdrTBL.30
INTEGER
R/W
1 = reflv-51-per
2 = reflv-58-per
l40sysSetupTBL
l40systemTBL.5
Aggregate
-
-
l40sysDateTime
l40sysSetupTBL.1
DisplayString
R/O
Date and Time
l40sysInfoTBL
l40systemTBL.6
Aggregate
-
-
l40sysInfoFirmware
l40sysInfoTBL.1
DisplayString
R/O
Firmware Version
l40sysInfoSer01
l40sysInfoTBL.2
INTEGER
R/O
1 = notavailable
2 = available
l40sysInfoSer02
l40sysInfoTBL.3
INTEGER
R/O
1 = notavailable
2 = available
• l40wfmTBL(3) group
MIB
OID
SYNTAX
ACCESS
VALUE/RANGE
l40wfmIntenConfigTBL
l40wfmTBL.1
Aggregate
-
-
l40wfmModeTBL
l40wfmIntenConfigTBL.1
Aggregate
-
-
l40wfmModeMode
l40wfmModeTBL.1
INTEGER
R/W
1 = parade
2 = overlay
l40wfmModeCh1Y
l40wfmModeTBL.2
INTEGER
R/W
1 = off
2 = on
l40wfmModeCh2Cb
l40wfmModeTBL.3
INTEGER
R/W
1 = off
2 = on
l40wfmModeCh3Cr
l40wfmModeTBL.4
INTEGER
R/W
1 = off
2 = on
l40wfmModeCh1G
l40wfmModeTBL.5
INTEGER
R/W
1 = off
2 = on
l40wfmModeCh2B
l40wfmModeTBL.6
INTEGER
R/W
1 = off
2 = on
l40wfmModeCh3R
l40wfmModeTBL.7
INTEGER
R/W
1 = off
2 = on
l40wfmModeCh1R
l40wfmModeTBL.8
INTEGER
R/W
1 = off
2 = on
l40wfmModeCh2G
l40wfmModeTBL.9
INTEGER
R/W
1 = off
2 = on
l40wfmModeCh3B
l40wfmModeTBL.10
INTEGER
R/W
1 = off
2 = on
l40wfmModeCh1X
l40wfmModeTBL.13
INTEGER
R/W
1 = off
2 = on
l40wfmModeCh2Y
l40wfmModeTBL.14
INTEGER
R/W
1 = off
2 = on
