19. Network Control
478
MIB
OID
SYNTAX
ACCESS
VALUE/RANGE
l40wfmModeCh3Z
l40wfmModeTBL.15
INTEGER
R/W
1 = off
2 = on
l40wfmIntenTBL
l40wfmIntenConfigTBL.2
Aggregate
-
-
l40wfmInten
l40wfmIntenTBL.1
INTEGER
R/W
-128 to 127
l40wfmColor
l40wfmIntenTBL.2
INTEGER
R/W
1 = white
2 = yellow
3 = cyan
4 = green
5 = magenta
6 = red
7 = blue
8 = multi
l40wfmScaleTBL
l40wfmIntenConfigTBL.3
Aggregate
-
-
l40wfmScaleInten
l40wfmScaleTBL.1
INTEGER
R/W
-8 to 7
l40wfmScaleColor
l40wfmScaleTBL.2
INTEGER
R/W
1 = white
2 = yellow
3 = cyan
4 = green
5 = magenta
6 = red
7 = blue
l40wfmScaleUnit
l40wfmScaleTBL.3
INTEGER
R/W
1 = unit-hdv-sdp
2 = unit-hdv-sdv
3 = unit-hdp-sdp
4 = unit-cv-dec
5 = unit-cv-hex
l40wfmScaleUnitNtsc
l40wfmScaleTBL.4
INTEGER
R/W
3 = unit-hdp-sdp
l40wfmScaleUnitPal
l40wfmScaleTBL.5
INTEGER
R/W
2 = unit-hdv-sdv
l40wfmScaleUnitFullRange
l40wfmScaleTBL.6
INTEGER
R/W
3 = unit-hdp-sdp
4 = unit-cv-dec
5 = unit-cv-hex
l40wfmScale75perCol
l40wfmScaleTBL.7
INTEGER
R/W
1 = off
2 = on
l40wfmScaleDisplay
l40wfmScaleTBL.8
INTEGER
R/W
1 = off
2 = on (*1)
2 = main (SER23) (*2)
3 = hdr (SER23) (*2)
4 = both (SER23) (*2)
*1 HDR OFF
*2 HDR ON
l40wfmGainTBL
l40wfmTBL.2
Aggregate
-
-
l40wfmGainVar
l40wfmGainTBL.1
INTEGER
R/W
1 = cal
2 = variable
l40wfmGainMag
l40wfmGainTBL.2
INTEGER
R/W
1 = x1
2 = x5
3 = x10
l40wfmGainValue
l40wfmGainTBL.3
DisplayString
R/W
0.2 to 2.000
l40wfmGainFilter
l40wfmGainTBL.4
INTEGER
R/W
1 = lowpass
2 = flat
l40wfmGainFilterCmp
l40wfmGainTBL.5
INTEGER
R/W
2 = flat
3 = lum
4 = flatlum
5 = lumchroma
l40wfmGainScaleJump
l40wfmGainTBL.6
INTEGER
R/W
1 = pos-0
2 = pos-10
3 = pos-20
