19. Network Control
479
MIB
OID
SYNTAX
ACCESS
VALUE/RANGE
4 = pos-30
5 = pos-40
6 = pos-50
7 = pos-60
8 = pos-70
9 = pos-80
10 = pos-90
11 = pos-100
12 = cursor
l40wfmSweepTBL
l40wfmTBL.3
Aggregate
-
-
l40wfmSweep
l40wfmSweepTBL.1
INTEGER
R/W
1 = h
2 = v
l40wfmSweepMagH
l40wfmSweepTBL.2
INTEGER
R/W
1 = x1
2 = x10
3 = x20
4 = blank
5 = active
l40wfmSweepMagV
l40wfmSweepTBL.3
INTEGER
R/W
1 = x1
2 = x20
3 = x40
l40wfmSweepH
l40wfmSweepTBL.4
INTEGER
R/W
1 = sweep-1h
2 = sweep-2h
l40wfmSweepV
l40wfmSweepTBL.5
INTEGER
R/W
1 = sweep-1v
2 = sweep-2v
l40wfmSweepField
l40wfmSweepTBL.6
INTEGER
R/W
1 = field1
2 = field2
l40wfmBlanking
l40wfmSweepTBL.7
INTEGER
R/W
1 = remove
2 = v
3 = h
4 = all
l40wfmBlankingCmp
l40wfmSweepTBL.8
INTEGER
R/W
1 = remove
2 = v
l40wfmMatrixTBL
l40wfmTBL.4
Aggregate
-
-
l40wfmMatrix
l40wfmMatrixTBL.1
INTEGER
R/W
1 = ycbcr
2 = gbr
3 = rgb
4 = composite
l40wfmMatrixRgb
l40wfmMatrixTBL.2
INTEGER
R/W
2 = gbr
3 = rgb
4 = composite
l40wfmMatrixYgbr
l40wfmMatrixTBL.3
INTEGER
R/W
1 = off
2 = on
l40wfmMatrixYrgb
l40wfmMatrixTBL.4
INTEGER
R/W
1 = off
2 = on
l40wfmCmpFormat
l40wfmMatrixTBL.5
INTEGER
R/W
1 = auto
2 = ntsc
3 = pal
l40wfmCmpSetup
l40wfmMatrixTBL.6
INTEGER
R/W
1 = setup-0p
2 = setup-75p
l40wfmMatrixXyz
l40wfmMatrixTBL.7
INTEGER
R/W
2 = gbr
3 = rgb
4 = composite
5 = xyz
l40wfmMatrixTBL
l40wfmTBL.4
Aggregate
-
-
l40wfmCursorMode
l40wfmCursorTBL.1
INTEGER
R/W
1 = off
2 = single
3 = both
