Leader LV5300A - Page 497

19. Network Control
480
MIB
OID
SYNTAX
ACCESS
VALUE/RANGE
l40wfmCursorSel
l40wfmCursorTBL.2
INTEGER
R/W
1 = x
2 = y
l40wfmCursorUnitX
l40wfmCursorTBL.3
INTEGER
R/W
1 = sec
2 = hz
l40wfmCursorUnitY
l40wfmCursorTBL.4
INTEGER
R/W
1 = mv
2 = per
3 = r-per
4 = dec
5 = hex
6 = hdr
l40wfmCursorUnitYCmp
l40wfmCursorTBL.5
INTEGER
R/W
1 = mv
2 = per
3 = r-per
l40wfmCursorRefset
l40wfmCursorTBL.6
INTEGER
R/W
1 (fixed)
l40wfmCursorRefX
l40wfmCursorTBL.7
INTEGER
R/W
0 to 927
l40wfmCursorDeltaX
l40wfmCursorTBL.8
INTEGER
R/W
0 to 927
l40wfmCursorTrackX
l40wfmCursorTBL.9
INTEGER
R/W
-927 to 927
l40wfmCursorRefY
l40wfmCursorTBL.10
INTEGER
R/W
-5000 to 15000
l40wfmCursorDeltaY
l40wfmCursorTBL.11
INTEGER
R/W
-5000 to 15000
l40wfmCursorTrackY
l40wfmCursorTBL.12
INTEGER
R/W
-15000 to 15000
l40wfmLineselTBL
l40wfmTBL.6
Aggregate
-
-
l40wfmLinesel
l40wfmLineselTBL.1
INTEGER
R/W
1 = off
2 = on
3 = cinelite
l40wfmLineselNo
l40wfmLineselTBL.2
INTEGER
R/W
0 to 32767
l40wfmLineselField
l40wfmLineselTBL.3
INTEGER
R/W
1 = frame
2 = field1
3 = field2
• l40vectorTBL(4) group
MIB
OID
SYNTAX
ACCESS
VALUE/RANGE
l40vectorIntenConfigTBL
l40vectorTBL.1
Aggregate
-
-
l40vectorDispMode
l40vectorIntenConfigTBL
.1
INTEGER
R/W
1 = vector
2 = fivebar
3 = histogram
4 = cie-diagram
l40vectorInten
l40vectorIntenConfigTBL
.2
INTEGER
R/W
-128 to 127
l40vectorColor
l40vectorIntenConfigTBL
.3
INTEGER
R/W
1 = white
2 = yellow
3 = cyan
4 = green
5 = magenta
6 = red
7 = blue
l40vectorVectorMode
l40vectorIntenConfigTBL
.7
INTEGER
R/W
1 = vector
2 = rgb-vector
3 = ycbcr-vector
l40vectorDispVecTBL
l40vectorTBL.2
Aggregate
-
-
l40vectorDispVecScaleTBL
l40vectorDispVecTBL.1
Aggregate
-
-
l40vectorDispVecScaleInten
l40vectorDispVecScaleTB
L.1
INTEGER
R/W
-8 to 7
l40vectorDispVecScaleColor
l40vectorDispVecScaleTB
L.2
INTEGER
R/W
1 = white
2 = yellow
3 = cyan
4 = green
