19. Network Control
493
MIB
OID
SYNTAX
ACCESS
VALUE/RANGE
curr
l40statusDataAncPktAribNetqV
Next
l40statusDataTBL.69
DisplayString
R/O
Video Next
l40statusDataAncPktAribNetqA
Curr
l40statusDataTBL.70
DisplayString
R/O
Audio Current
l40statusDataAncPktAribNetqA
Next
l40statusDataTBL.71
DisplayString
R/O
Audio Next
l40statusDataAncPktAribNetqD
Curr
l40statusDataTBL.72
DisplayString
R/O
Downmix Current
l40statusDataAncPktAribNetqD
Next
l40statusDataTBL.73
DisplayString
R/O
Downmix Next
l40statusDataAncPktSmpteAfd
Code
l40statusDataTBL.74
DisplayString
R/O
AFD Code
l40statusDataAncPktSmpteAfd
Frame
l40statusDataTBL.75
DisplayString
R/O
Coded Frame
l40statusDataAncPktSmpteAfd
BarFlg
l40statusDataTBL.76
DisplayString
R/O
Bar Data Flags
l40statusDataAncPktSmpteAfd
BarVal1
l40statusDataTBL.77
DisplayString
R/O
Bar Data Value1
l40statusDataAncPktSmpteAfd
BarVal2
l40statusDataTBL.78
DisplayString
R/O
Bar Data Value2
l40statusDataFreqDev
l40statusDataTBL.79
DisplayString
R/O
<-100ppm, -100 to
+100ppm, >+100ppm
• l40eyeTBL(7) group (LV5300/LV5300A/LV7300-SER02)
MIB
OID
SYNTAX
ACCESS
VALUE/RANGE
l40eyeConfigTBL
l40eyeTBL.1
Aggregate
-
-
l40eyeMode
l40eyeConfigTBL.1
INTEGER
R/W
1 = eye
2 = jit
l40eyeInten
l40eyeConfigTBL.2
INTEGER
R/W
-128 to 127
l40eyeScaleInten
l40eyeConfigTBL.3
INTEGER
R/W
-8 to 7
l40eyeColor
l40eyeConfigTBL.4
INTEGER
R/W
1 = white
2 = yellow
3 = cyan
4 = green
5 = magenta
6 = red
7 = blue
l40eyeScaleColor
l40eyeConfigTBL.5
INTEGER
R/W
1 = white
2 = yellow
3 = cyan
4 = green
5 = magenta
6 = red
7 = blue
l40eyeJitInten
l40eyeConfigTBL.6
INTEGER
R/W
-128 to 127
l40eyeJitScaleInten
l40eyeConfigTBL.7
INTEGER
R/W
-8 to 7
l40eyeJitColor
l40eyeConfigTBL.8
INTEGER
R/W
1 = white
2 = yellow
3 = cyan
4 = green
5 = magenta
6 = red
7 = blue
l40eyeJitScaleColor
l40eyeConfigTBL.9
INTEGER
R/W
1 = white
2 = yellow
3 = cyan
