19. Network Control
494
MIB
OID
SYNTAX
ACCESS
VALUE/RANGE
4 = green
5 = magenta
6 = red
7 = blue
l40eyeGainTBL
l40eyeTBL.2
Aggregate
-
-
l40eyeGainMode
l40eyeGainTBL.1
INTEGER
R/W
1 = cal
2 = variable
l40eyeGainVar
l40eyeGainTBL.2
DisplayString
R/W
0.50 to 2.00
l40eyeFilter
l40eyeGainTBL.3
INTEGER
R/W
1 = filter-100khz
2 = filter-10khz
3 = filter-1khz
4 = filter-100hz
5 = filter-10hz
6 = filter-timing
7 = filter-alignment
l40eyeSweep
l40eyeGainTBL.4
INTEGER
R/W
1 = sweep-2ui
2 = sweep-4ui
3 = sweep-16ui
l40eyeJitGainMag
l40eyeGainTBL.5
INTEGER
R/W
1 = x1
2 = x2
3 = x8
l40eyeJitGainMag12g
l40eyeGainTBL.6
INTEGER
R/W
1 = x1
2 = x2
3 = x4
4 = x16
l40eyeJitFilter
l40eyeGainTBL.7
INTEGER
R/W
1 = filter-100khz
2 = filter-10khz
3 = filter-1khz
4 = filter-100hz
5 = filter-10hz
6 = filter-timing
7 = filter-alignment
l40eyeJitSweep
l40eyeGainTBL.8
INTEGER
R/W
1 = sweep-1h
2 = sweep-2h
3 = sweep-1v
4 = sweep-2v
l40eyePeakHoldTBL
l40eyeTBL.3
Aggregate
-
-
l40eyePeakHoldMode
l40eyePeakHoldTBL.1
INTEGER
R/W
1 = off
2 = on
l40eyePeakHoldClear
l40eyePeakHoldTBL.2
INTEGER
R/WO
1 (fixed)
l40eyeTrigger
l40eyePeakHoldTBL.3
INTEGER
R/W
1 = run
2 = stop
l40eyeDisplayMode
l40eyePeakHoldTBL.4
INTEGER
R/W
1 = single
2 = dual
l40eyeJitDisplayMode
l40eyePeakHoldTBL.5
INTEGER
R/W
1 = single
2 = dual
l40eyeDataTBL
l40eyeTBL.4
Aggregate
-
-
l40eyeDataAmp
l40eyeDataTBL.1
DisplayString
R/O
Amp
l40eyeDataTr
l40eyeDataTBL.2
DisplayString
R/O
Tr
l40eyeDataTf
l40eyeDataTBL.3
DisplayString
R/O
Tf
l40eyeDataTj
l40eyeDataTBL.4
DisplayString
R/O
Tj
l40eyeDataJ
l40eyeDataTBL.5
DisplayString
R/O
Jitter
l40eyeDataOr
l40eyeDataTBL.6
DisplayString
R/O
Or
l40eyeDataOf
l40eyeDataTBL.7
DisplayString
R/O
Of
l40eyeDataPeakTj
l40eyeDataTBL.8
DisplayString
R/O
Peak Tj
l40eyeDataPeakJit
l40eyeDataTBL.9
DisplayString
R/O
Peak Jitter
l40eyeHistogramTBL
l40eyeTBL.5
Aggregate
-
-
