19. Network Control
495
MIB
OID
SYNTAX
ACCESS
VALUE/RANGE
l40eyeHistogramMode
l40eyeHistogramTBL.1
INTEGER
R/W
1 = off
2 = on
l40eyeHistogramInten
l40eyeHistogramTBL.2
INTEGER
R/W
-8 to 7
l40eyeHistogramColor
l40eyeHistogramTBL.3
INTEGER
R/W
1 = white
2 = yellow
3 = cyan
4 = green
5 = magenta
6 = red
7 = blue
• l40audioTBL(8) group
MIB
OID
SYNTAX
ACCESS
VALUE/RANGE
l40audioDispMode
l40audioTBL.1
INTEGER
R/W
1 = lissajou
2 = surround
3 = meter
4 = status
l40audioMeterTBL
l40audioTBL.2
Aggregate
-
-
l40audioMeterRange
l40audioMeterTBL.1
INTEGER
R/W
1 = range-60dBFS
2 = range-90dBFS
3 = mag
l40audioMeterResponse
l40audioMeterTBL.2
INTEGER
R/W
1 = truepeak
2 = ppm
3 = vu
l40audioMeterPpmMode
l40audioMeterTBL.3
INTEGER
R/W
1 = mode1
2 = mode2
l40audioMeterPeakMeter
l40audioMeterTBL.4
INTEGER
R/W
1 = true
2 = ppm1
3 = ppm2
l40audioMeterPeakHold
l40audioMeterTBL.5
INTEGER
R/W
0 = hold-0
5 = hold-500ms
10 = hold-1000ms
15 = hold-1500ms
20 = hold-2000ms
25 = hold-2500ms
30 = hold-3000ms
35 = hold-3500ms
40 = hold-4000ms
45 = hold-4500ms
50 = hold-5000ms
55 = hold
l40audioMeterOverLevel
l40audioMeterTBL.6
DisplayString
R/W
-40.0 to 0
l40audioMeterWarningLevel
l40audioMeterTBL.7
DisplayString
R/W
-40.0 to 0
l40audioMeterRefLevel
l40audioMeterTBL.8
DisplayString
R/W
-40.0 to 0
l40audioMeterLevelValueDispla
y
l40audioMeterTBL.9
INTEGER
R/W
1 = instantly
2 = peakhold
l40audioMeterPeakHoldReset
l40audioMeterTBL.10
INTEGER
R/WO
1 (fixed)
l40audioLissajouTBL
l40audioTBL.3
Aggregate
-
-
l40audioLissajouInten
l40audioLissajouTBL.1
INTEGER
R/W
-8 to 7
l40audioLissajouScaleInten
l40audioLissajouTBL.2
INTEGER
R/W
-8 to 7
l40audioLissajouDisplay
l40audioLissajouTBL.3
INTEGER
R/W
1 = multi
2 = single
l40audioLissajouForm
l40audioLissajouTBL.4
INTEGER
R/W
1 = xy
2 = matrix
l40audioLissajouAutoGain
l40audioLissajouTBL.5
INTEGER
R/W
1 = off
2 = on
l40audioSurroundTBL
l40audioTBL.4
Aggregate
-
-
