3. SPECIFICATIONS
41
Gamut Error Detects gamut errors
Detection Range
Upper limit 90.8 to 109.4%
Lower Limit -7.2 to 6.1%
Low-Pass Filter
Format
Low-Pass Filter
HD/SD: 1 MHz
HD: 2.8 MHz SD: 1 MHz
SD 720×487
Approx. 1 MHz (EBU R103-2000)
Approx. 1 MHz
SD 720×576
Approx. 1 MHz (EBU R103-2000)
Approx. 1 MHz
HD 1280×720
Approx. 1 MHz
Approx. 2.8 MHz
HD 1920×1080 (frame rate ≤ 30 Hz)
Approx. 1 MHz (IEEE STD 205)
Approx. 2.8 MHz
HD 1920×1080 (frame rate > 30 Hz)
Approx. 2 MHz
Approx. 5.5 MHz
HD 2048×1080 (frame rate ≤ 30 Hz)
Approx. 1 MHz (IEEE STD 205)
Approx. 2.8 MHz
HD 2048×1080 (frame rate > 30 Hz)
Approx. 2 MHz
Approx. 5.5 MHz
4K 3840×2160 (frame rate ≤ 30 Hz)
Approx. 4 MHz
Approx. 11 MHz
4K 3840×2160 (frame rate > 30 Hz)
Approx. 8 MHz
Approx. 22 MHz
4K 4096×2160 (frame rate ≤ 30 Hz)
Approx. 4 MHz
Approx. 11 MHz
4K 4096×2160 (frame rate > 30 Hz)
Approx. 8 MHz
Approx. 22 MHz
Area Specification 0.0 to 5.0%
Time Specification 1 to 60 frames
Composite Gamut Error Detects level errors that occur when component signals are
converted to composite signals
Detection Range
Upper limit 90.0 to 135.0%
Lower Limit -40.0 to 20.0%
Low-Pass Filter The same as the gamut error
Area Specification 0.0 to 5.0%
Time Specification 1 to 60 frames
SDI Analysis Features
Event Log Display
Function Records detected errors, events—such as the instrument
switching between input signals, and timestamps.
Log Capacity Up to 1000 events
Operation Logs all events from start to finish
Data Output Overwrite mode, Stop after 1,000 events
