4. PANEL DESCRIPTION
54
No.
Name
Description
[See also] 16, “Status Display”
16
▲
SELECT
▼
Carries out the corresponding function menu operation.
[See also] 5.5.2, “Function Menu Operations”
17
EYE
(SER02)
The eye pattern is displayed. You can change the layout as you like.
[See also] 17, “EYE PATTERN DISPLAY (SER02)”
18
MULTI
Shows a combination of measurement screens. You can change the layout
as you like.
[See also] 6.3.7, “MULTI-SCREEN DISPLAY”
19
MEM
Press this key to register or delete a single preset setting, or copy all preset
settings.
[See also] 9, "PRESET FEATURE"
20
RECALL
Press this key to recall a preset setting configuration.
[See also] 9, "PRESET FEATURE"
21
S-CUT
Loads panel settings, saves a screen capture to the USB memory device,
adjusts the intensity, performs cursor measurement, or adjusts the
headphone volume.
[See also] 6.4, “Operation Key Actions”
22
Power Switch
Press to turn the instrument on. Hold down to turn the instrument off.
[See also] 5.1, “Turning the Instrument On and Off”
