4. PANEL DESCRIPTION
56
Table 4-3 LV5300/LV5300A/LV5350 rear panel description
No.
Name
Description
1
SDI OUTPUT
SDI signal output connectors
[See also] 5.4.1, “SDI Signal I/O.”
2
SDI INPUT
SDI signal input connectors.
[See also] 5.4.1, “SDI Signal I/O.”
3
DC INPUT
DC inlet.
[See also] 5.1, “Turning the Instrument On and Off”
4
EXT REF
External reference input connector. This is a loop-through connector.
[See also] 5.4.2, “External Sync Signal Input”
5
Serial number
label
The serial number is printed on this label.
6
REMOTE
15-pin D-sub remote connector. This can be used to execute actions such as
recalling preset settings.
7
ETHERNET
Ethernet port. Supports TELNET, FTP, SNMP, HTTP, and SNTP.
