Usage constraints

Accessing the CPUECTLR_EL1

The CPU Extended Control Register can be written only when the system is idle. Arm

recommends that you write to this register after a powerup reset, before the MMU is enabled.

This register can be read using MRS with the following syntax:

MRS <Xt>,<systemreg>

This register can be written using MSR with the following syntax:

MSR <systemreg>, <Xt>

This syntax is encoded with the following settings in the instruction encoding:

<systemreg> op0 op1 CRn CRm op2

CPUECTLR_EL1 11 000 1111 0001 100

Accessibility

This register is accessible in software as follows:

<systemreg> Control Accessibility

E2H TGE NS EL0 EL1 EL2 EL3

CPUECTLR_EL1 x x 0 - RW n/a RW

CPUECTLR_EL1 x 0 1 - RW RW RW

CPUECTLR_EL1 x 1 1 - n/a RW RW

'n/a' Not accessible. The PE cannot be executing at this Exception level, so this access is not possible.

Traps and enables

For a description of the prioritization of any generated exceptions, see Synchronous exception

prioritization in the Arm

Architecture Reference Manual Armv8, for Armv8-A architecture

profile for exceptions taken to AArch64 state.

Access to this register depends on bit[1] of ACTLR_EL2 and ACTLR_EL3.

B2 AArch64 system registers

B2.26 CPUECTLR_EL1, CPU Extended Control Register, EL1

reserved.

B2-179

Non-Confidential
